- UV-5R 5W Dual Band Radio
|SKU: 28-020-105
| In Stock Out of stock
UV-5R 5W Dual Band Radio
$24.99
Sale
$29.99
- | Compare
UPC: 757440562857
English Description ↤ Click
Deutsche Beschreibung ↤ Klicken
Descrizione italiana ↤ Clic
Description en français ↤ Cliquez sur
Descripción en español ↤ Hacer clic
About Baofeng UV-5R
▶ The Baofeng UV-5R is a compact handheld radio scanner transceiver providing 4 watts in the frequency range of 136-174/420-450 MHz.
▶ Other features include: selectable wide/narrow, battery save function, VOX, DCS/CTCSS encode, key lock and a built-in flashlight. Selectable frequency steps include: 2.5, 5, 6.25, 10, 12.5 and 25 kHz. omes with ANT5 SMA-J flexible antenna, BL-5 Li-ion battery (7.4V 1800 mAh), belt clip, wrist strap, AC adapter, and drop-in charging tray.
▸ FCC ID: 2AJGM-UV5R
▸ 128 Channels 50 CTCSS and 104 CDCSS Dual-Band Display, Dual Freq. Display, Dual-Standby, A/B band independent operation | High/Low TX power selectable: Busy channel lock-out(BCLO)
▸ Keypad Lock: Channel Step: 2.5/5/6.25/10/12.5/25KHz | Voice companding: 50 CTCSS/ 104DCS coder & tone searching
▸ Tri-color background light selectable: 0-9 grades VOX selectable | Large LCD Display
▸ Emergency Alert: 25KHz/12.5KHz Switchable | LED Flashlight: Hight /Low RF Power Switchable
CLICK HERE to download CHIRP. Support CHIRP quick programming.
Functions:
1. Frequency Range: 136-174 / 420-450 MHz
2. Dual-Band Display, Dual Freq. Display, Dual-Standby
3. Output Power: 4 /1Watts
4. 128 Channels 50 CTCSS and 104 DCS
5. Built-in VOX Function
6. 1750Hz Brust Tone
8. LED Flashlight
9. Large LCD Display
10. Hight /Low RF Power Switchable
11. 25KHz/12.5KHz Switchable
12. Emergency Alert
13. Low Battery Alert
14. Battery Saver
15. Time-out Timer
16. Keypad Lock
17. Monitor Channel
18. Channel Step: 2.5/5/6.25/10/12.5/25KHz
19. ROGER SET
Specifications:
▶ Output: 4W/1W
▶ Channel: 128
▶ Frequency stability: ± 2.5ppm
▶ Antenna: Dual band High Gain antenna
▶ Antenna impedance: 50Ω
▶ Operating voltage: DC 7.4V
▶ Wide/Narrow Band(25kHz/12.5kHz)
▶ Weight: 500g (including battery, antenna)
Note
Antenna Type: Compatible with SMA-Female Antenna
Earpiece & Programming Type: Compatible with K-plug earpiece/cable
Package Content:
1 x BaoFeng UV-5R Two-Way Radio
1 x 7.4V 1800mAh Li-ion Battery Pack
1 x Antenna
1 x Earphone Mic/Headset
1 x Belt Clip
1 x Hand Strap
1 x ENG Manual
1 x Adapter
1 x Desktop Charger
DeutscheBeschreibung
Über Baofeng UV-5R Dual-Band Walkie Talkie
Das Baofeng UV-5R ist das ideale Funkgerät für aktive Personen, die schnell und unkompliziert kommunizieren wollen oder müssen ohne auf Mobilfunknetzwerke angewiesen zu sein. Dabei kann es sich z.B. um Ranger oder Wächter handeln. Aber auch im anspruchsvollen Freizeitsport findet das Gerät seine Anwendung. Es kann als Notrufgerät verwendet werden, wenn man sich mal alleine auf eine Tour begibt oder um eine kurzzeitige Trennung von Wander- oder Kletterpartnern zu überbrücken und bei der gegenseitigen Lokalisierung zu helfen. Das Design des Geräts vereint Handlichkeit und guten Stil in einem. Des Weiteren verfügt das Gerät über einen großen ansteuerbaren Frequenzbereich auf dem gesendet werden kann.
Der transcevier ist ein Mikro-Miniatur Multiband-Transceiver mit umfangreichem Frequenzbereich, was zusammen mit unübertroffener Überwachungsmöglichkeit Ort-Bereich Zwei-Weg-Amateur Kommunikation ermöglicht. Dualband-Display-Standby Transceiver mit Wide Band Reichweite.
• VHF UHF Funkgerät, Dual-Band Display, Dual Freq. Display, Dual-Standby.
• Mit voller HD LED Display. Der Bildschirm hat eine exquisite Deutlichkeit.
• Das Material des Rahmenes hat schon aktualisiert. Metallisch, langlebiger und modisch.
• 128 Kanäle, 50 CTCSS und 104 CDCSS.
• Bequemer und humanistisch. Lieferumfang: UV-5R Funkgerät, Headset, Gürtelclip, 1800mAh Akku, Ladegerät, Deutsches Handbuch.
Technische Daten
Frequenzbereich: 136-174MHZ und 420-450HZ (TX/RX)
Antenneimpedanz: 50ohm; Betriebsspannung: DC 7.4V
Kanalmenge: 128; Frequenzstabilität: ±2.5ppm
Abemessungen: 100 x 52 x 32 mm
Gewicht: 580g
Spezifikation
ROGER SET
Time-out Timer (TOT)
Busy-Kanal Lock-out (BCLO)
Tastatursperre
Monitor-Kanal
LED Flashlight
Großes LCD Display
per PC programmierbar
Eingebaute VOX Funktion
Hoch /niedrig HF-Leistung umschaltbar
A/B-band unabhängiger Betrieb
Emergency Alarm
Niedrige Batterie Alarm
Lieferumfang
1 x Baofeng UV-5R Funkgerät
1 x Ladegerät
1 x Lithium-Akku
1 x Anschlusskabel
1 x Antenne
1 x Sicherheitsklemme
1 x Kopfhörer
1 x Deutsches Handbuch
Descrizione italiana
• Baofeng UV-5R sono ricetrasmittenti portatili che operano, rispettivamente, nelle bande radio di VHF e UHF.
• 128 canali, 50 frequenze CTCSS, 104 codici DCS selezionabili, Tono ripetitore 1750 Hz ; Potenza: 1W/5W, Portata da 3 a 6 Km
• Schermo retroilluminato in 3 diversi colori: Giallo, blu e viola; In più, la batteria risulta molto efficiente: fino a 24 ore di autonomia!
• Incorpora inoltre tutte le caratteristiche indispensabili, come:funzione Scan e funzione TOT. Funzione VOX per comunicazioni a mani libere, Funzione di allarme (emergenza)
• È ideale per attività all’aperto ed per l'utilizzo in grandi ambienti industriali e professionali ad esempio aeroporti, stadi, caccia, magazzini, fabbriche...
Caratteristiche
Frequenza:VHF/UHF Band
Fino a 128 canali
Potenza: 1W/5W
Channeling: 25KHz / 12.5KHz
Batteria 1800 mAH Li-on 7.4V
Jack per cuffie Kenwood a 2 pin
Funzione Vox e Scanner
Blocco canale occupato
Squelch regolabile in 9 livelli
Blocco tastiera
Funzione Monitor
Display LCD
Risparmio automatico della batteria
Highlight:
Nonostante le dimensioni ridotte, il walkie incorpora una tastiera pienamente funzionante: tutte le caratteristiche necessarie per essere uno dei migliori sul mercato.
Lo schermo ha una scelta di 3 colori diversi per ottimizzare la lettura e con la tastiera alfanumerica si piò facilmente impostare la frequenza e i canali.
La funzione VOX permetterà di comunicare a mani libere, senza dover premere un solo pulsante.
UV-5R sono dotati di una batteria agli ioni di Litio da 1800mAh che garantisce fino ad 24 ore di autonomia.
Incluso nella Confezione:
1x Baofeng UV-5R
1x Batteria agli Ioni di Litio da 1800mAh
1x Aggancio per la Cintura
1x Antenna Bibanda VHF/UHF
1x Caricatore da Tavolo
1x Manuale Utente
1x Auricolari
1x Laccetto da Polso
Description en français
✔ Radio UHF/VHF compacte, 128 Canaux,, Puissance d'émission : VHF: 5W / UHF 4W
✔ Ecran LCD : Son écran LCD vous permet de contrôler d'un simple coup d'oeil le canal utilisé, l'état de la batterie ou encore la mise en route de la fonction Vox.
✔ Portée pouvant atteindre 5 km : le Baofeng UV-5R Plus vous fait bénéficier de communication dans un périmètre de 5 km en champ libre.
✔ Fonction VOX : La fonctionnalité VOX vous permet non seulement d'enclencher la communication à la voix, mais également de parler sans devoir attendre que votre interlocuteur ait terminé.
✔ Ce modèle comprend une oreillette confort offerte (style de port : tour d'oreille) , pratique pour passer toutes vos communicationsles mains libres.
Une fonction:
Ecran LCD
Fonction VOX
Portée pouvant atteindre 5 km en champ libre
Bi-Bande : 128 Canaux
Double PTT pour une puissance haute ou basse d'émission
Mode Dual watch (double veille)
Vibreur
Surveillance de pièce
Squelch automatique
Verrouillage clavier
Indicateur de batterie faible
Economiseur de batteries
Caractéristiques techniques
Bande de fréquences : VHF&UHF
Nombre de canaux : 128
Sélection de la puissance haute ou basse: 1W/4W
Codes CTCSS/DCS : 38/104
Batterie 1800mAh Li-ion
Caractéristiques principales
Fonction Vibreur, Scan, Vox, double veille, hors de portée
Fonction appel d'urgence
Ecran LCD
Indicateur de batterie faible
Economiseur de batteries
Squelch automatique
Verrouillage clavier
Roger beep
Vibreur
Livré aver :
1x Radio Baofeng UV-5R
1x Oreillette
1x Batterie
1 x Antenne
1x Chargeur de bureau
1x Clip ceinture
1x Dragonnes
1x Mode d'emploi
Descripción en español
• Walkie Talkie portatil radio aficionado, doble banda VHF/UHF y 128 canales de memoria
• Selección Alta/ Baja potencia:1W/5W; Tono de repetidor 1750 Hz, Display LCD retroiluminado
• Capacidad para programar hasta128 canales con diferentes CTCSS o DCS
• Indicador de bateria baja,Batería de 1.800 mAh Li-ion, que permite el uso durante unas 12 horas y la carga completa en 3 horas
• Múltiples funciones, como el scanner de canales, función VOX que le permetirá usar el manos libres y bloqueo de pantalla
Especificaciones:
Frecuencias radio afincionado: VHF /UHF
Trabaja en a U-V, V-V i U-U
Hasta 128 memorias/canals
Selección Alta/ Baja potencia:1W/5W
Batería : 1800 mAh, LI.ion 7,4v
Accesorios audio: 2 pins tipo Kenwood
Peso: 63 g
Función
50 subtonos CTCSS/104 CDCSS
Tono de repetidor 1750 Hz
Pasos de canalización: 25KHz/12.5KHz
Función emergencia SOS
Funciones Vox y Scan
Display LCD retroiluminado
Indicador de bateria baja
Función TOT: limitador tiempo Tx
Bloqueo canal ocupado
Squelch regulable en 9 niveles
Bloqueo del teclado
Función de frecuencia invertida
Step de frecuencia: 12.5/25 kHz
Reset de ajustes/canales
Display LCD retroiluminado ajustable en 3 colores diferentes
Alcance: de 3-5 km
¿Qué hay en la caja?
Se incluye auricular, pinza de cinturón, correa para la muñeca, manual del usuario, antenna VHF/UHF de alta ganancia, Batería de iones de litio de 1800mAh y cargador rápido de sobremesa.
