General
Frequency Range 136-174 & 400-520MHz
Channel Capacity 128
Channel Spacing 12.5(narrow)25KHz(wide)
Operated Voltage 7.4V
Frequency Stability 2.5ppm
Operated Temperature -30 º C ~+60 º C
Antenna Impedance 50 Ω
Transmitting Current About 1.5A

Transceiver
Max Frequency Deviation 5KHz (N)/ 2.5KHz (W)
Adjacent Channel Power ≤-65dB≤-60dB
FM Noise(N/W) ≥-45dB≥-40dB
Modulation sensitivity 8-12mV
Dimensions 62.5*123*36mm
Weight About 251g

Receiver
Sensitivity(12dB SINAD) ≤0.25 uV
Max Audio power output 1W @10%
Audio distortion ≤10%
Adjacent Channel Power ≤-65dB≤-60dB
Inter modulation ≥65dB
Spurious response ≥65dB
Receiver current ≤380mA

• Walkie talkie
• Li-Ion battery
• Antenna
• Belt Clip
• User's Manual
• Charger
