Frequency Range: VHF 144-148MHz & UHF 420-450MHz
Frequency Stability ±2.5ppm
Antenna High gain Dual Band antenna
Antenna Impedance 50Ω
Operating Voltage DC 7.4V
Mode of operation Simple or semi-duplex
Dimension(W x H x D) 100 x 52 x 32 mm
Weight 250g(including battery, antenna)
Antenna SMA -Female
Earpiece / mic type Kenwood Plug type

Transmitter
Output power 4W/1W (Max 5W)
Modulation Mode 16kΦF3E / 11kΦF3E
Maximum deviation <5kHz(W) /<2.5kHz(N)
Intermediation distortion <10%
Adjacent Ch. power ≤-65dB(W) / ≤-60dB(N)
Pre-emphasis 6dB
Current ≤1.6A(5W)
>Receiver
RF Sensitivity -122dbm(12db SINAD)
Audio power ≥0.5W
Audio Distortion ≤10%
Intermediation ≤-65dB(Wide)/≤-60dB(Narrow)
Selectivity ≤-65dB(Wide)/≤-60dB(Narrow)
Spurious Rejection ≤-65dB
Blocking ≥85dBuv/m

• Walkie talkie
• Li-Ion battery
• Belt Clip
• User's Manual
• Charger
