Press and hold the scan button, and place it near the radio you want to scan, upon radio transmission, UV-5RM Plus will display the frequency(±2.5 PPM), CTCSS or DCS tones, or ‘NONE’ if CTCSS or DCS is absent.
Equipped with a Type-C charging port, this radio can be recharged from anywhere and anytime using various power sources such as a wall socket, power bank, car charger, or laptop, ensuring continuous communication.
With the NOAA weather band scan and reception function, you can keep yourself safe during severe weather by receiving emergency alerts for hurricanes, tornadoes, floods, and other hazards.
Specifications:
Receiver Frequency:
FM 88-108 MHZ;AM 108-136MHz(VFO-0nly),VHF 136-174MHZ,220-260MHz(VFO-0nly),UHF350-390MHz,400-520MHz(VFO-0nly),[EU FM 88-108MHZ: AM 108-136MHz(VFO-0nly), VHF & UHF]
Transmission Frequency:136-174 & 220-260 & 400-480 MHz
Channel Spacing: 25.0 KHz (Wide)/12.5 KHz (Narrow)
Memory Channel: 999 Groups
Operation Voltage: DC 7.4 V ±10%
Transmission Current: ≤2800 mA
Receive Sensitivity: 0.25 μV (12dB SINAD)
Rated Audio Power Output: 1W @16 ohms
Receive Current: ≤380 mA
Connection for Accessories: 2-pin Kenwood jack
Antenna Impedance: 50 Ohm
Standard Antenna:
Antenna Gain: 2.0 dBi
Antenna SWR: ＜1.2
Frequency: 136-174/400-520 MHz
Antenna Connector Type: SMA-Female
Max Power: 10 Watts
Length: 8.3’’
Long Antenna:
Antenna Gain: 2.15 dBi
Antenna SWR: ＜1.2
Frequency: 144/430MHz
Antenna Connector Type: SMA-Female
Max Power: 10 Watts
Length: 15.5’’
Recommended Accessories
1. Original Programming Cable
2. Original Desktop Charger
3. Original BL-5RH Battery
4. Original Shoulder Mic
4. BS-UV25 Tactical Speaker Mic
