Main Features
Frequency Range: UHF 400-470 MHZ （RX/TX）
Up to 16 Channels
Commercial FM radio
Chinese/English Language
50 Groups CTCSS，105 Groups of standard DCS
Time-out timer(TOT)
Battery saving function
Alarm function
USB rapid charge
Programmable by PC

General
Frequency range: UHF400-470MHz
Memory channels: 16 Groups
Operation voltage: DC3.7V
Frequency stability: ±2.5ppm
Operation temperature: -20℃—+50℃
Mode of operation: Simplex
Antenna impedance: 50Ω

Transmitter
RF Power: ＜5W
Maximum deviation(W/N): ≤5KHz/≤2.5KHz
Spurious emission: ≤7.5uW
Adjacent channel power: ≤-65dB/≤-60dB
SNR(W/N): ≥-45dB/≥-40dB
QT/DQT (W/N): 0.7±0.1KHz/0.4±0.1KHz
Modulation sensitivity: 8—12mV
Transmission current: ≤1.2A
