Frequency Range: VHF 144-148MHz/UHF 420-450MHz
Storage Channel 16
Rated voltage DC 7.4V
Frequency Stability ±2.5ppm
Work Temperature -20 ℃ to +60℃
Battery Capacity H-1800mAh (Li-ion Battery)
Battery Life About 12 Hours
Frequency Combination PLL frequency synthesis
Antenna Impedance 50 Ω
Wok Mode Same Frequency simplex Operation or Different Frequency simplex Operation
Dimension 135(H)*64(W)*40(D)mm (Excluded Antenna)

Transmitter
Output Power 7W(H)/5W(M)/1W(L)
Modulation Mode(W/N Band) 16KΦF3E
Maximum Frequency Deviation (W/N Band) ≤5 KHz
Spurious Power ≤7.5 μW
Adjacent channel power ≤-65dB/≤-60dB
Audio Distortion <5 %
SNR ≥-45dB/≥-40dB
CTSCC/DCS Frequency Deviation(W/N Band) 0.7±0.1KHz (W), 0.4±0.1KHz (N)
Modulation Sensitivity 8-12mV
Transmitting Current ≤1500mA

Receiver
Sensitivity <0.20 μ V (12dB SINAD)
Audio Power >2W@10%
Inter modulation Interference Resistance ≥65dB (W), ≥55dB (N)
Adjacent channel Sensitivity (W/N Band) ≥65dB (W), ≥55dB (N)
Audio Distortion 5 %
Receiving Current ≤ 380m A

• Walkie talkie
• Li-Ion battery
• Belt Clip
• User's Manual
• Charger
